How to use the Condition block
Understand how to use the Condition block to create decision points and logical paths in your agent flow.
The Condition block is used to create decision points in a flow, allowing paths to diverge based on specific conditions. For example, you can implement logic such as:
“If Score is greater than 10, follow this path. Otherwise, follow another path.”
How Conditions Work
A condition block evaluates one or more comparisons, which can be combined using logical operators AND or OR:
- AND: All comparisons must evaluate to
true
for the condition to pass. - OR: At least one comparison must evaluate to
true
for the condition to pass.
Each comparison checks a value against a specific operator.
Operators Available and Their Behavior
Operator | Description | Example |
---|---|---|
Equal to | Matches if the provided value is strictly equal to the target value. | "age" = 25 will match if age is exactly 25 . |
Not equal | Matches if the provided value is not equal to the target value. | "status" Not equial "active" will match if status is not "active" . |
Contains | Matches if the provided value contains the target value (or shares any elements if a list is provided). | "tags" contains "important" will match if tags includes "important" . |
Does not contain | Matches if the provided value does not contain the target value (or does not share any elements if a list is provided). | "tags" does not contain "important" will match if tags excludes "important" . |
Greater than | Matches if the provided value is greater than or equal to the target value. | "score" Greater than 20 will match if score is greater than or equal to 20 . |
Less than | Matches if the provided value is less than or equal to the target value. | "score" Less than 20 will match if score is less than or equal to 20 . |
Is set | Matches if the provided value is neither null , undefined , nor an empty string. | "user.name" is set will match if user.name is not empty. |
Is empty | Matches if the provided value is null , undefined , or an empty string. | "user.email" is empty will match if user.email is empty. |
Starts with | Matches if the provided value starts with the target value. | "username" starts with "admin" will match if username begins with "admin" . |
Ends with | Matches if the provided value ends with the target value. | "filename" ends with ".jpg" will match if filename ends with ".jpg" . |
Matches regex | Matches if the provided value conforms to a valid regex pattern. | "message" matches /^hello$/ will match if message is exactly "hello" . |
Does not match regex | Matches if the provided value does not conform to a regex pattern. | "input" does not match /^[a-z]+$/ will match if input contains non-lowercase letters. |
Regex Examples
Regex patterns can help match complex string conditions:
- Exact Match:
/^hello$/
matches the string"hello"
, but not"hello world"
. - Contains Substring:
/hello/
matches any string containing"hello"
(e.g.,"hello world"
). - Case-Insensitive Match:
/hello/i
matches"Hello"
or"HELLO"
. - Digit Check:
/[0-9]+/
matches strings with one or more digits, such as"123"
or"abc123"
.
Note: Regex patterns must start and end with /
to be valid.
Example Use Case
If you want to route a flow based on the user’s score, you can define:
-
Condition:
Score > 20
Path A: “High Score Route”
Path B: “Low Score Route” -
Condition:
User Tags contains "premium"
Path A: “Premium Features Route”
Path B: “Basic Features Route”
This enables dynamic and personalized user interactions based on predefined logic.
